'EDB Konsulent'
Author
Lassen, Niels Klitgaard
Term
10. Term
Education
Publication year
2006
Abstract
Rapporten beskriver retningslinjer for at modellere et tog som en graf. I modellen repræsenterer knuder (vertices) de ydelser, som kunderne efterspørger, og kanter (edges) repræsenterer de konkrete løsninger, der leverer disse ydelser. Ved kanterne angives oplysninger om komponenters egenskaber, og ved knuderne angives betingelser og begrænsninger. Grafen beskriver de vigtigste forbindelser mellem komponenter og delsystemer, så den kan behandles af en algoritme.
This report presents guidelines for modeling a train as a graph. In the model, vertices (nodes) represent the services requested by customers, and edges (links) represent the concrete solutions that deliver those services. Edges carry information about component properties, while vertices include conditions and constraints. The graph captures the most important connections between components and subsystems, so it can be processed by an algorithm.
[This abstract was generated with the help of AI]
Documents
